Unit 14 Lesson 3: Basic Electronics
This lesson is for advanced students, and advanced 5-8th graders as well. For this lesson, you’ll need the Electronic Learning Lab by Radio Shack (or other similar electronic learning lab boards… there are many of them out there.) They come with tons of experiments that cover both basic and digital electronics projects! It includes everything you need for all the projects in these two lessons.
Exploring electronics can be a fun and rewarding experience. In workbook 1, we’ll cover some basics of electronics as well as explore analog circuitry to get a better understanding of how analog circuits work.
We’ll start our journey by learning about the buzzer, light emitting diodes (LEDs), resistors, capacitors, and other electronic parts by building circuits that use these components. I hope you like to make noise because we are going to build a lot of circuits that generate all kinds of sounds.
Of course, building circuit without understanding how the components work isn’t as much fun, so we’ll also take a close look at resistors, capacitors, along with other electronic components.
The 555 timer is a well known and respected timer IC that we’ll be getting know very well. We’ll explore a lot of different ways to use the 555 timer by creating a lot of circuits that take advantage of the 555 timer’s versatility.
Controlling voltage in a circuit is very important, so we’ll explore voltage dividers as well as taking a close look at voltage regulators.
Some other components we’ll be building experiments with are:
Operational Amplifier (Op-Amp for short): An amplifier take a input signal and boosts it so if can drive a device or components that requires a higher strength signal. A good example of this is your stereo system, the signal going to the speakers are amplified so that the speakers can produce the sound.
Analog Comparator: An analog comparator compares two different voltages and produces an output based on those two inputs.
Electronics are a lot of fun and understanding electronics will help you understand the world around you. So, enough talk, let’s get started building some cool circuits!
If you find your students are thirsty for more reading content that is provided in the project kit, then these are my three favorites. There are THREE books recommended (not required) for this unit at the 9-12 grade level. When your kids hound you for more projects, pick up these texts for further projects. Here they are:
- Getting Started in Electronics by Forrest Mims III (optional)
- MAKE: Electronics by Charles Pratt (optional)
- Practical Electronics for Inventors by Paul Scherz (optional)
|Ham Radio Essentials|
“CQ, CQ.. calling CQ 20 meters. This is KJ6ZFH calling. Kilo Juliet Six Zulu Foxtrot Hotel in San Luis Obispo calling CQ 20 meters. Hello CQ, CQ, CQ 20 meters. This is KJ6ZFH calling. Kilo Juliet Six Zulu Foxtrot Hotel in San Luis Obispo calling CQ 20 meters and standing by for a call.” What […]
|Push Button Switch|
In this experiment you’ll learn how to use the one of the Learning Lab’s push button swtiches to turn on the buzzer, then we’ll add in the DPDT (Double Throw Double Pole) switch to see how two switches can be used to control the buzzer.
|Use The DPDT Switch|
LEDs are a lot of fun, and in this experiment we’ll use the DPDT (Double Throw Double Pole) to turn on the buzzer and light up the LED while using a different voltage to control both of them.
|Control 4 LEDs|
Did you know that the DPDT (Double Throw Double Pole) switch can control up to four different devices? In this experiment we’ll see how the DPDT switch can be used to control multiple devices at the same time!
|Connect Two Switches in Series|
Switches are a lot of fun, they allow us to control when a circuit is on and when it’s off. In this experiment we’ll see how two switches can be connected in series to control when a single device is on or off.
|Connect Two Switch in Parallel|
We’ve seen how switches can be used to turn stuff on and off, now let’s take a look at how a switch in different locations can turn the same thing on or off. A lot like a doorbell with a button at the front door and a button at the back door.
|Use The Relay to Control The Buzzer Experiment 1|
Relays are really neat, they help us control high power circuits with low power circuits. In this experiment you’ll get to use the normally off contacts of the relay to control the buzzer using a switch.
|Use The Relay to Control The Buzzer Experiment 2|
Did you know the relay also has normally closed contact as well? In this experiment we’ll see how these contacts differ from the normally open contact with the learning lab’s buzzer.
|Use a Relay as an Electromagnetic Buzzer|
We’ve seen how we can use the really to control the buzzer, now let’s use the relay as a buzzer! In this experiment we’ll see how to connect the relay to work as a buzzer. However, be careful the relay isn’t really designed to work like this for very long, but it’s okay for a […]
|Build a Fixed Voltage Divider|
Seeing electricity turn things on and off is a lot of fun, but we also need to have methods to see what’s going on in the circuit. What good is an alarm clock with numbers? Or a clock with no hands? In this experiment we’ll see how to use the learning lab’s meter to tell […]
|Build an Adjustable Voltage Divider|
Now it’s time to learn about voltage dividers and in this experiment we’ll build one and use the meter to see what voltage the divider is supplying to the circuit.
|Build an LED Brightness Control|
Yeah, it’s time to get back to some LED magic. In this experiment we’ll build an LED brightness control. We’ll be able to see the LED light up just a little or a whole lot.
|Build a Light-Activated Light|
Photoresistors are a lot of fun, the can turn a circuit on or off based on how much light is getting to them. In this experiment we’ll see how a photoresistor can be used to turn an LED on or off.
|Build a Simple LED Flasher|
Wow, now it’s time to really get deeper into electronics and use our first IC in a circuit. IC stands for integrated circuit and the one we’ll be using is a legend in the electronics community. We are going to use a 555 timer to build an LED flasher!
|Build a 555 “Black Box”|
Ready to make some noise? We are going to build a “black box” test circuit using the 555 timer. A black box is a circuit that’s there when you need it, and in this one we will build it to produce a tone for us when we need it. Trust me, this one is a […]
|Use a Potentiometer to Change|
Our black box test circuit is capable of generating a lot of different sounds. In this experiment let’s take a look at how we can use resistors to generate different tones from our black box!
|Use a Photoresistor to Change|
Really ready to hear some weird sounds from the black box test circuit? Well, in this experiment we’ll modify the black box to use the photoresistor to generate sounds with our black box, and trust me, you won’t want to miss this one!
|Use an Adjustable Voltage Diver to Change The Tone Frequency|
Let’s change the tone up a little bit using a voltage divider. In this experiment we’ll see how we can use a variable resistor, a potentiometer, to control the tone frequency from the black box.
|Use a Light-Sensitive Voltage Divider|
In this black box experiment let’s use the photoresistor to reduce the tone frequency our black box generates. And, if you remember from a previous experiment the photoresistor can help us make some really wild sounds!
|Use Resistors And a “Keyboard” to Control The Tone Frequency|
Wow, we’ve had a lot of fun making strange sounds from the black box. Now, let’s try something a little different. In this experiment we’ll setup three push button switches to generate tones for us, with each switch giving us a different tone.
|Make the Buzzer a Chirper and Warbler|
Making weird sounds from the buzzer is a lot of fun, so let’s do some more! In this experiment we’ll use a capacitor to make the buzzer “chirp” for us! And then we’ll switch things up a bit and make the buzzer “warbler”.
|Use Capacitors to Generate|
The black box test circuit has been a lot of fun, and this next experiment is going to be a noisy one, too! In this experiment we’ll setup our black box test circuit to generate either a rising tone or a falling tone using two capacitors and two push button swtiches.
|Use Capacitors and a “Keyboard|
Time for some more keyboard action with the “black box”, in this experiment we’ll create a keyboard that will allow us to control the tone frequency of our black box. This experiment is neat since you can use the keyboard to generate up to nine different tones.
|Use an Adjustable RC Circuit to Create|
We’ve had a ton of fun making a whole lot of different sounds with our black box test circuit. Now, let’s get more specific and make a space gun sound effect with the black box!
|Use a Switched RC Circuit|
We can do even more sound effects with the black box and we’ve had a lot of fun doing it. Now, it’s time to create another sound effect and this time we’ll make a siren using the black box test circuit and a few other components.
|The Console LED Digital Display|
I just love LEDs, they are fun to look at and provide useful purpose of communicating information from the circuit to us humans. Your learning lab also has a seven segment display built in, so let’s take a look at this and see how it works.
|Use the 7-Segment LED|
Did you know that the seven segment display can create a whole lot of different symbols and characters? In this experiment we’ll make a small square on the seven segment display and get a better feel for what the display can do!
|Transistors and How to Use Them|
Transistors are powerful electronic components that help us control a circuit. You can think of a transistor as an electronic switch. And, in this experiment we’ll see how a NPN (negative, positive, negative) transistor works and how to use them.
|Build an NPN Transistor Circuit|
Did you know a transistor can be only partially on? Well, in this experiment we take a look at turning a NPN transistor only partially on to light an LED. We’ll be using a potentiometer to control the transistor and be able to adjust when the transistor is off, to partially on, to full on.
|Drive a Relay With a Transistor|
Electronic devices can either use a little bit of power or a whole lot of power. Think of your microwave, it uses a lot of power, but a lamp only uses a little bit of power. We use relays to allow low power circuits to control more powerful circuits. And, in this experiment we’ll use […]
|Build a Simple Two-Transistor Oscillator|
Time to make more noise! In this experiment we are going to use two transistors to make an oscillator. An oscillator is a circuit that generates a frequency, a pulse of signals, and we’ll use the oscillator to drive the speaker. You’ll be able to hear the pulse our oscillator generates as a tone from […]
|Resistors and How to Use Them|
Resistors are a very important part of electronics, in fact without them we wouldn’t even have electronics. Resistors help us control the flow of current through a circuit and protect components from being damaged. This video talks about what resistors are, how to read them, and how to use them.
|Troubleshooting Problem Circuits|
When you wire up a circuit, it may not work right away. But don’t worry, even experience engineers face this problem, sometimes we don’t get it right the first time either! This video covers some basic steps you can take to track down problems and fix them.
|Build a Two-Transistor Dual-LED Flasher|
Let’s have some more audio fun. In this experiment we are going to build a two transistor audio amplifier using two NPN transistors. We’ll be able to use the earphone as a microphone and listen in on just about anything.
|Build a Power FET to Control the Brightness|
Let’s take a look at a new electronic component, the Power MOSFET. Now, we don’t have to call them “MOSFET” all the time, we can just call them “FET” and most people do. A FET is a lot like a transistor, but works a bit differently and in this experiment we’ll take a look at […]
|Build a Power FET Timer|
Now it’s time to have some fun with timers. And in this experiment we’ll be using a power MOSFET and a timer circuit to control how long an LED stays lit.
|Build a Power FET|
Now that we’ve made a timer using an LED, let’s change the circuit up a bit and use the timer to control the buzzer. More noise, yeah!
|Analog ICs Provided|
Let’s take a moment and get a better understanding of the analog ICs included with your project learning lab. In this video we’ll take a look at those different ICs and get a better understanding of what they are, what they do, and how to use them.
|Build a Super-Sensitive Op Amp|
Now it’s time to listen in on some ants! Yes, I said ants! In this experiment we’ll be using two Operational Amplifiers, Op Amp for short, to build a super sensitive audio amplifier. This amplifier is so sensitive it can pick up very low sounds and amplify them so we can hear what’s going on.
|Add a Signal Strength Indicator|
But there’s no LED, and you know I love LEDs, so let’s add an LED to the super sensitive audio amplifier to include an LED. And, we’ll use the LED to indicate how strong the signal the microphone (earphone) is picking up.
|Add a Sound Level Meter|
Well, maybe not. The LED is nice and all, but it doesn’t really give us a good feeling for the strength of the signal. So, let’s change the circuit to use the meter instead. This will give us a better visual indicator of the signal strength and also allow us to assign a value to […]
|Build a Percussion Instrument Synthesizer|
We’ve had a lot of fun making a lot of different circuits, now let’s step it up a notch and build a percussion instrument synthesizer. This circuit will build on what we’ve learned so far and use a lot of different parts to create a synthesizer that will generate a plucked string or drum sound. […]
|Comparators and How to Use Them|
A comparators is a form of an Op AMP that can either be on or off. This may not sound useful, but you can do things with comparators that are very useful. To demonstrate this, let’s take a look at comparators, what they are, and how to use them. In this experiment we’ll get use […]
|Build an Experimental Op Amp Audio Oscillator|
Now, let’s take a closer look at Op Amps and what they can do. In this experiment we’ll use an Op Amp to generate a frequency and then use that signal to produce a sound from the speaker.
|Build an Op Amp Tone Mixer|
Making sounds has been a lot of fun, so lets do some more! In this experiment we’ll use two Op Amps to build a tone mixer and I think you’ll be surprised at the sounds you can get out of this project!
|Build an Op Amp Bargraph Light Meter|
Oh, this one is about LED bargraphs, and you know I love LEDs. In this experiment we are going to build an LED bargraph and then use that bargraph to measure how much light is hitting the photoresistor. In essence, we are going to build an LED bargraph light meter!
|Build a Buzzer Triggered by Light or Darkness|
Let’s have some more fun with the photoresistor and build a buzzer that has two modes. The first will be the buzzer triggering off of light and the second will be the buzzer triggering off of darkness. This circuit is exactly how a laser eye alarm works and we can try this by setting the […]
|Build an 8-Level LED Bargraph Readout|
Did you like the bargraph experiment? Well, in this one we are going to build a bigger and better bargraph. In this experiment we’ll build a 8 segment LED bargraph that has a sensitivity adjustment. You know me and LEDs, so let’s get wiring!
|555 Timer Circuits|
Let’s have some more 555 timer fun and build a keyboard oscillator. In this experiment we’ll use a 555 timer and 4 switches, each with a different value capacitor, to create up to 16 different tones.
|Build a Voltage Controlled Oscillator|
Did you know that VCO stand for Voltage Controller Oscillator? Well, in this experiment we are going to build one using a 555 timer, a few capacitors, and a potentiometer. We’ll then send the signal from the VCO to the speaker and make some neat tones!
|Build a Programmable Timer|
Timers are really neat, and we’ve already seen a few in action. Now, let’s build one that operate the buzzer and an LED and can run both for up to 100 seconds. We’ll be using a 555 timer, several capacitors, a potentiometer, and a few switches as well. Sound like fun to me!
|Build a Fully Adjustable Siren|
We’ve created a lot of circuits together and now it’s time to start looking at a new part, the 4046 is a Phased-Locked Loop IC that contains both analog and digital circuitry inside. Well be using the 4046 to help generate the siren sound for this circuit. We’ll also be using the 555 timer and […]
|Digital Logic Experiments|
If you enjoyed these experiments, then you’re in for a real treat, because there’s a lot MORE experiments in Lesson 4: Digital Logic! Since the mid 1980’s, digital electronics have slowly become an ever increasing part of our lives. And now, you’d be hard pressed to find any device that doesn’t use digital electronics. Digital […]
